We’re in the process of rebuilding our server infrastructure. We’re shifting from debian sarge with postgres 7.4 to Ubuntu 7 and postgres 8. We currently investigate the stability and scalability of various rails stacks. Also we’re looking at different solutions of handling high volume static content delivery ie. delivery of our map tiles. (This could apply to any static content like thumbnails) During our research into reverse proxy alternatives, Paul Gold put me onto varnish.
Varnish is written from the ground up to be a high performance caching reverse proxy. The author built it due to his frustration at squid and he provides a detailed analysis of why squid sucks. In his own words…
Varnish is written from the ground up to be a high performance caching reverse proxy. Squid is a forward proxy that can be configured as a reverse proxy. Besides – Squid is rather old and designed like computer programs where supposed to be designed in 1980.
– Poul-Henning Kamp, Varnish architect and coder.
I’ve done a little bit of testing against lighttpd 1.4, apache 2.2, vs varnish with some surprising results.
My test involved using apache bench (ab) in a brute force test of fetching a 1k, 5k, 10k and 20k image file. I tested against 50,100, 200 concurrent users. (eg. ab -n 20000 -c 100 http://test/5kimage.jpg ) I tested against a default installation of apache 2.2 and lighttpd 1.4.12.
Here are the results:
File Size |
Concurrent Users |
Apache 2.2(reqs/ sec) |
Lighttpd 1.4.12(reqs/ sec) |
Varnish 1.1.1(reqs/ sec) |
1k
|
50
|
3792
|
2050
|
5386
|
1k
|
100
|
3949
|
2135
|
5471
|
1k
|
200
|
3973
|
1946
|
5228
|
5k
|
50
|
2087*
|
1655
|
2075*
|
5k
|
100
|
2051*
|
1764
|
2076*
|
5k
|
200
|
2006*
|
1764
|
2062
|
10k
|
50
|
1063*
|
1065*
|
1065*
|
10k
|
100
|
1059*
|
1064*
|
1060*
|
10k
|
200
|
1056*
|
1056*
|
1055*
|
20k
|
50
|
571*
|
560*
|
570*
|
20k
|
100
|
569*
|
560*
|
564*
|
20k
|
200
|
566*
|
562*
|
566*
|
* = Denotes network throughput was approaching 10.93Mb / sec . The size of the network connection was effectively putting a cap on the throughput.
A couple things to note from the testing. First, Apache forks a lot of processes, while lighttpd and varnish fork threads.Also, the CPU seemed to be under less load using lighttpd and varnish compared to apache.
From the results, Varnish excels at caching small files, and as fast as the other servers at higher file sizes. I want to do a bit more testing against varnish. For my next set of testing, I’ll test the webservers against 100 random images and post the results.
